HIKVISION DS-7616NXI-K2(D) 1U K Series AcuSense 4K NVR 16-ch PoE
SKU: DS-7616NXI-K2(D)Networking › Network Video Recorders (NVR)
฿7,488
Price includes 7% VATPrice updated November 1, 2026
In stock4 units3 years manufacturer's warranty
For orders placed before 12:00 on a business day; weekends excluded
GenuineFree delivery from ฿5,000Tax invoice
1U Hikvision Network Video Recorder (NVR) supports up to 16 IP cameras with AcuSense technology and records video at maximum 4K resolution, suitable for enterprise-level security systems
Key features
- Supports up to 16 IP cameras with 16 PoE ports
- Records video at maximum 12 MP resolution for 2 channels
- Supports decoding up to 12 channels at 1080p
- AcuSense technology reduces false alarms from inaccurate detection
- Supports full AI analytics: face, intrusion, ANPR
Product description
DS-7616NXI-K2(D) from Hikvision is a 1U Pro-Series NVR designed to support medium to large-scale CCTV camera systems, supporting up to 16 IP camera channels with PoE connectivity that reduces cable clutter and improves installation efficiency. The system supports video recording at up to 12 MP resolution for 2 channels, 8 MP for 3 channels, or 4 MP for 6 channels, and supports decoding up to 12 channels at 1080p or 6 channels at 4 MP resolution with 30 fps. The system also supports intelligent analytics via AcuSense technology, including AI by Device and AI by Camera, such as face detection, intrusion detection, object throwing alerts, license plate recognition (ANPR), and behavior analysis (VCA).
More features
- Features HDMI and VGA for independent display output
- Supports H.265+/H.265/H.264+/H.264 to reduce recording file size
- Supports storing up to 20,000 face images (1 GB total)
- Supports two-way audio via 1 RCA port
- Supports network connectivity of 160 Mbps in both directions
Pros and limitations
Pros
- Supports up to 16 IP camera channels with built-in PoE, reducing cabling costs.
- Records video at up to 12 MP resolution for 2 channels, with decoding capability for 12 channels at 1080p.
- AcuSense technology effectively reduces false alarms from inaccurate detection.
- Supports full AI analytics such as face detection, intrusion detection, and ANPR without requiring additional software installation.
- Designed as a 1U rack-mountable unit, ideal for server cabinets or control centers.
Limitations
- No CVBS port for analog output.
- Supports up to 2 HDDs (8 TB each), which may be limiting for large-scale systems requiring long-term storage.
- No USB port for external devices such as flash drives or printers.
Who it is for
Ideal for organizations, shopping malls, factories, and commercial centers requiring professional CCTV systems with real-time AI analytics such as face detection, intrusion alerts, and tracking of people or vehicles.
Connectivity
RJ-45, USB, HDMI, VGA
Specifications (40)
- Weight
- 4.5 kg
- Dimensions
- 436 mm × 44 mm × 205 mm
- Rack Mount
- 1U rack-mountable
- VGA Output
- 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
- Audio Input
- 1-ch RCA (2.0 Vp-p, 1 KΩ)
- HDMI Output
- 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
- PoE Support
- 16-port PoE
- Audio Output
- 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
- Certification
- CE, FCC, RoHS, CCC
- Input Voltage
- 100–240 V AC, 50/60 Hz
- Two-Way Audio
- 1-ch, RCA (Linear, 1 KΩ)
- Video Encoding
- H.265+/H.265/H.264+/H.264
- Decoding Format
- H.265/H.265+/H.264+/H.264
- Operating System
- HIKVISION NVR OS
- Network Interface
- 16 × RJ45 10/100/1000 Mbps
- Power Consumption
- Up to 70 W
- Security Features
- User management (up to 128 users), role-based access control, encryption, login failure lockout
- Storage Expansion
- Supports up to 2 SATA III HDDs (up to 8 TB each)
- Video Output Mode
- HDMI/VGA independent output
- Facial Recognition
- Facial Detection and Analytics: Face picture comparison, human face capture, face picture search
- Incoming Bandwidth
- 160 Mbps
- Outgoing Bandwidth
- 160 Mbps
- Decoding Capability
- AI on: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p
- Decoding Frame Rate
- 30 fps (for supported resolutions)
- Face Picture Library
- Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
- Management Interface
- Web browser, Hik-Connect, HikCentral, Hik-Viewer Pro
- Recording Resolution
- 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
- Synchronous playback
- 16-ch
- Intelligent Analytics
- AI by Device: Facial recognition, perimeter protection, motion detection 2.0; AI by Camera: Facial recognition, perimeter protection, throwing objects from building, motion detection 2.0, ANPR, VCA
- Face Picture Comparison
- 4-ch
- Video Output Resolution
- Up to 4K (3840 × 2160) via HDMI
- Network Protocol Support
- TCP/IP, UDP, HTTP, HTTPS, FTP, SMTP, NTP, DHCP, DNS, PPPoE, IGMP, SNMP, ONVIF, RTSP
- Decoding Resolution Support
- Up to 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
- Motion Detection 2.0 (By Camera)
- All channels
- Motion Detection 2.0 (By Device)
- All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
- Perimeter Protection (By Camera)
- All channels
- Perimeter Protection (By Device)
- 2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
- Power over Ethernet (PoE) Budget
- Up to 160 W
- Facial Detection and Analytics Performance
- 1-ch, 8 MP
- Number of Camera Channels (IP Video Input)
- 16-ch
Datasheets and manuals straight from the manufacturer — select a document to open or download it.
13 questions
Frequently asked questions about this product
Compiled from manufacturer information
How many 4K resolution cameras can the DS-7616NXI-K2(D) support simultaneously?
Supports recording up to 12 MP for 2 channels, 8 MP for 3 channels, or 4 MP for 6 channels. Supports decoding up to 12 channels at 1080p or 6 channels at 4 MP with 30 fps
Can it work with other Hikvision camera models?
Yes, it works with all Hikvision IP camera models that support ONVIF and RTSP protocols, especially K Series, DS-2CD, and DS-76xx cameras with AcuSense support
What additional equipment is needed for installation?
No additional accessories are required, as it has built-in 16 PoE ports that deliver power and data over a single cable
How many face images can it analyze simultaneously?
Supports face comparison for up to 4 channels simultaneously and can store up to 20,000 face images (total 1 GB)
Can it be used in large-scale systems?
Ideal for medium to large-scale systems, especially shopping centers, factories, or office buildings requiring intelligent AI-powered security monitoring
Are there additional USB or LAN ports?
No additional USB or LAN ports, but has 16 LAN ports for camera connection and supports management via web browser or Hik-Connect app
Can it display simultaneously on multiple monitors?
Yes, it supports independent display output via HDMI and VGA simultaneously, or mirrored display on a single monitor.
Does it have a backup system?
Supports network-based backup (FTP, NTP) and can connect to NAS or external storage systems via ONVIF and RTSP protocols.
Is it in stock?
The HIKVISION DS-7616NXI-K2(D) 1U K Series AcuSense 4K NVR 16-ch PoE is in stock and ready to ship. Orders placed before 12:00 on a business day are delivered within 1–3 business days (Bangkok and vicinity) or 2–5 business days (other provinces). Order online at store.gist.co.th or contact our sales team at 092-251-4017.
How much does it cost?
The price is ฿7,488 (including 7% VAT). It is in stock and ready to ship. Business customers can request a quotation at sales@gist.co.th.
How long is the warranty?
Warranty period: 3-year warranty (manufacturer's terms). To make a warranty claim, call 092-251-4017 or 065-523-5262, or email sales@gist.co.th (Mon–Fri 9:00–18:00), then send the product with your order number to our head office, or bring it to the head office in person.
How long does delivery take?
Orders placed before 12:00 on a business day are delivered within 1–3 business days (Bangkok and vicinity) or 2–5 business days (other provinces). Free delivery on orders of ฿5,000 or more (a ฿150 delivery fee applies below this amount).
Is it genuine?
Genuine products sourced from distributors in Thailand, covered by the manufacturer's warranty. Full tax invoices are available.
