TP-LINK LS1005 | 5-Port 10/100Mbps Desktop Switch
SKU: LS1005Networking › Network Switches
Please enquire before ordering
The distributor has not yet confirmed the latest price and availability (last checked Jul 27, 2026)
092-251-4017Awaiting stock confirmationManufacturer's warranty
GenuineFree delivery from ฿5,000Tax invoice
Unmanaged network switch for expanding internet connectivity in offices or homes. Supports all 5 ports at 10/100 Mbps. Easy to use and energy efficient.
Key features
- Supports all 5 ports at 10/100 Mbps
- Auto-MDI/MDIX enables immediate plug-and-play operation without configuration
- Green Ethernet technology for energy savings
- Fanless design for silent, non-disruptive operation
- Easy installation with immediate Plug and Play functionality
Product description
The TP-LINK LS1005 is an unmanaged network switch designed to efficiently expand internet connectivity in offices or homes. It features 5 RJ45 ports supporting speeds of 10/100 Mbps, with Auto-MDI/MDIX technology that eliminates the need to worry about network cable types. The switch operates fanlessly, ensuring silent and noise-free performance. Equipped with Green Ethernet technology, it significantly reduces power consumption, with a maximum power consumption of only 1.65W and a low heat output of 5.627 Btu/hr, making it ideal for use in confined spaces or near users without causing disturbance.
More features
- Supports storage temperature up to 70°C
- Plastic housing for durability and lightweight design
- Supports IEEE 802.3x Flow Control to prevent packet loss
Pros and limitations
Pros
- Fanless design ensures quiet, non-disruptive operation
- Supports Auto-MDI/MDIX for easy setup—no need to worry about cable types
- Green Ethernet technology helps reduce power consumption
- Durable plastic construction with lightweight design
- Supports storage temperature up to 70°C
Limitations
- Not supported Gigabit (1000 Mbps)
- No SFP port for long-distance expansion
- No web or application-based management system
Who it is for
Ideal for home or small business users who need to expand network ports in a home or small office without configuration—supports devices such as computers, printers, CCTV cameras, and gaming consoles
Specifications (24)
- Port type
- RJ45
- Management
- Unmanaged
- Port speed
- 10/100 Mbps
- Power Input
- 5VDC/0.6A
- Fan Quantity
- Fanless
- Certification
- CE, FCC, RoHS
- Casing Material
- Plastic
- Mounting Option
- Desktop or Wall-mounting (based on LS1005G information)
- Number of ports
- 5
- Storage Humidity
- 5%~90% non-condensing
- Advanced Features
- Green Technology, 802.3X Flow Control, Back Pressure
- Installation Type
- Desktop
- Replacement Model
- TL-SF1005D
- Operating Humidity
- 10% ~ 90% non-condensing
- Storage Temperature
- -40°C~70°C (-40°F~158°F)
- Transmission Method
- Store and Forward
- External power supply
- External Power Adapter (Output: 5VDC/0.6A)
- Max. Heat Dissipation
- 5.627 Btu/hr
- Operating Temperature
- 0°C~40°C (32°F~104°F)
- Dimensions (W x D x H)
- 3.3 × 1.8 × 0.9 in. (83.6 × 45.7 × 22.8 mm)
- Max. Power Consumption
- 1.65W
- Supports Auto-MDI/MDIX
- Yes
- Standards and Protocols
- IEEE 802.3i/802.3u/802.3x
- Supports Auto-Negotiation
- Yes
Datasheets and manuals straight from the manufacturer — select a document to open or download it.
13 questions
Frequently asked questions about this product
Compiled from manufacturer information
Does LS1005 support Gigabit (1000 Mbps) speeds?
Not supported. This switch only supports 10/100 Mbps. For Gigabit devices, we recommend upgrading to the TL-SF1005D or LS1005G model.
How many printers and CCTV cameras can be connected simultaneously?
Up to 5 devices can be connected simultaneously via all RJ45 ports. Each port supports devices operating at 10/100 Mbps, such as standard printers or CCTV cameras.
Can it be used in a very hot room?
Yes. The switch operates within a temperature range of 0°C to 40°C and can be stored up to 70°C, making it suitable for typical office or home environments.
Do I need anything extra for installation?
No additional accessories are required. Simply plug in the power adapter and connect devices via the RJ45 ports to use immediately. Comes with a 5VDC/0.6A power adapter.
Is there a management system or app control?
No. As an unmanaged switch with Plug and Play functionality, it does not support web or app-based management.
Can it work with standard LAN cables?
Yes, any standard Ethernet LAN cable can be used, especially Cat5e or Cat6 cables. Since this model supports Auto-MDI/MDIX, crossover cables are not required.
Are there firmware updates?
No firmware updates are available for this model, as it is an unmanaged switch without a management system.
Can it be mounted on a wall?
Yes. It is designed to support both desktop and wall-mounting installation. Although not explicitly stated in all documentation, the similar LS1005G model specifies wall-mount support.
Is it in stock?
We are confirming the latest stock and price of the TP-LINK LS1005 | 5-Port 10/100Mbps Desktop Switch with the distributor. Please contact us before ordering at 092-251-4017 or sales@gist.co.th.
How much does it cost?
The distributor has not yet confirmed the latest price and availability. Please contact us before ordering at 092-251-4017 or sales@gist.co.th.
How long is the warranty?
The warranty follows the manufacturer's terms for each model; ask our sales team for the warranty period of this model. To make a warranty claim, call 092-251-4017 or 065-523-5262, or email sales@gist.co.th (Mon–Fri 9:00–18:00), then send the product with your order number to our head office, or bring it to the head office in person.
How long does delivery take?
Orders placed before 12:00 on a business day are delivered within 1–3 business days (Bangkok and vicinity) or 2–5 business days (other provinces). Free delivery on orders of ฿5,000 or more (a ฿150 delivery fee applies below this amount).
Is it genuine?
Genuine products sourced from distributors in Thailand, covered by the manufacturer's warranty. Full tax invoices are available.
