VIGI InSight S245 4MP Full-Color Dome Camera 2.8mm Lens
SKU: VIGI-INSIGHT-S245-2.8MMNetworking › IP Cameras (CCTV)
฿2,088
Price includes 7% VATPrice updated November 1, 2026
In stock17 unitsManufacturer's warranty
For orders placed before 12:00 on a business day; weekends excluded
GenuineFree delivery from ฿5,000Tax invoice
4MP dome CCTV camera with white light and infrared, supports two-way communication, works both day and night, weather and impact resistant
Key features
- 4MP resolution 2688 x 1520 pixels, sharp and clear in every detail
- 2.8 mm lens with 100° horizontal viewing angle for wide area coverage
- Supports night vision with white light and IR up to 30 meters
- Uses H.265+ technology to reduce bandwidth usage by 50%
- Intelligent motion detection that distinguishes between people and vehicles
Product description
The VIGI InSight S245 CCTV camera features 4MP resolution and a 2.8 mm lens for a 100° wide viewing angle, ideal for comprehensive surveillance of large areas. It supports night vision with white light and infrared up to 30 meters, and includes intelligent motion detection that accurately distinguishes between people and vehicles. This camera uses H.265+ technology to reduce bandwidth usage by up to 50% while maintaining high video quality. It also features behavioral analytics such as intrusion detection, object left behind, and abnormal sound detection. The camera supports cloud connectivity and the VIGI App for real-time mobile monitoring.
More features
- Supports two-way communication via built-in microphone and speaker
- IP67 rated waterproof and dust resistant, IK10 impact resistant
- Supports MicroSD storage up to 512 GB
- Connects via PoE or 12V DC power supply, easy to install
- Analyzes human and vehicle behavior through cloud-based system
Specifications (71)
- API
- Open Network Video Interface (Profile G/S/T)
- ROI
- 1 Region
- SNR
- ≥ 52 dB
- WDR
- 120 dB
- Lens
- 2.8 mm
- ONVIF
- Yes
- Sensor
- 1/2.7” Progressive Scan CMOS
- Bitrate
- 64 Kbps to 512 Kbps
- Aperture
- F1.6
- Security
- Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X authentication
- Pan angle
- 0° to 355°
- Frame rate
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Light type
- 2× IR LED, 2× White LED
- Net weight
- 0.62 Kg
- Resolution
- 2688 x 1520
- Basic event
- Motion detection(Enhanced with Human & Vehicle Classification), Camera Tampering, Exception (Illegal Login)
- Smart event
- Intrusion Detection, Line-Crossing Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection, People Detection, Vehicle Detection, Abnormal Sound Detection, Scene Change Detection
- Cloud system
- Yes
- Main bitrate
- 256 Kbps to 6 Mbps
- Network port
- 1 RJ45 10/100M Self-Adaptive Ethernet Port
- OSD settings
- Yes
- Power supply
- DC 12V DC ± 5%, Max. 10.54 W, 5.5 mm Coaxial Power Plug
- Reset button
- Yes
- Audio bitrate
- 64 Kbps(G.711 alaw)
- H.264 profile
- High Profile
- H.265 profile
- Main Profile
- Light control
- Auto/Scheduled/Always on/Always off
- Day/night mode
- Unified/Scheduled/Auto
- Focus distance
- 2.8 mm
- Bitrate control
- CBR, VBR
- Built-in memory
- Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB
- Main frame rate
- 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Noise filtering
- Yes
- Privacy shutter
- Up to 4 Masks
- Supports H.264+
- Main Stream Supported
- Supports H.265+
- Main Stream Supported
- Alarm connection
- Memory Card Video Recording, Upload to FTP server, Push Notifications, Active Defence-Sound Alarm, Active Defence-Light Alarm, Email Alarm, Send to Alarm Server
- Built-in speaker
- Yes
- Control software
- VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client
- Image adjustment
- Mirror, Rotation, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White balance
- Network protocol
- TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
- PoE power supply
- Yes
- Storage humidity
- 95% or Less (Non-Condensing)
- Audio compression
- Yes
- Image enhancement
- BLC/3D DNR/HLC/Smart IR
- Video compression
- H.265+/H.265/H.264+/H.264
- Day and night mode
- IR Cut Filter
- Detection distance
- 27 m (89 ft); 64 m (210 ft)
- Maximum resolution
- 2688 x 1520
- Operating humidity
- 95% or Less (Non-Condensing)
- Supported browsers
- Google Chrome® 57 and above, Firefox® 52 and above, Safari® 11 and above, Microsoft® Edge 91 and above
- Vertical pan angle
- 0° to 75°
- Built-in microphone
- Yes
- Storage temperature
- -40 °C to 60 °C (-40 °F to 140 °F)
- Horizontal pan angle
- 0° to 346°
- Minimum illumination
- 0.005 Lux; 0 Lux with IR/White light
- Simultaneous viewing
- 3 Main Streams & 3 Sub-Streams
- Illumination distance
- 30 m (98 ft)
- Operating temperature
- -30 °C to 60 °C (-22 °F to 140 °F)
- Two-way communication
- Two-Way Audio
- Diagonal viewing angle
- 118°
- Main video compression
- H.265+
- Vertical viewing angle
- 54°
- Camera housing material
- Metal
- Identification distance
- 13 m (43 ft); 6 m (20 ft)
- Audio sampling frequency
- 8KHz
- Horizontal viewing angle
- 100°
- Image parameter switching
- Yes
- Infrared glare protection
- Prevent overexposure to infrared light
- Human and vehicle analytics
- Search and filter to people or vehicle of interest based on many different attributes
- Secondary video compression
- H.265/H.264
Datasheets and manuals straight from the manufacturer — select a document to open or download it.
7 questions
Frequently asked questions about this product
Compiled from manufacturer information
What are the main specifications?
Main specifications of the VIGI InSight S245 4MP Full-Color Dome Camera 2.8mm Lens: API: Open Network Video Interface (Profile G/S/T); ROI: 1 Region; SNR: ≥ 52 dB; WDR: 120 dB; Lens: 2.8 mm; ONVIF: Yes; Sensor: 1/2.7” Progressive Scan CMOS; Bitrate: 64 Kbps to 512 Kbps; Aperture: F1.6; Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X authentication; Pan angle: 0° to 355°; Frame rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
What are the key features?
4MP resolution 2688 x 1520 pixels, sharp and clear in every detail; 2.8 mm lens with 100° horizontal viewing angle for wide area coverage; Supports night vision with white light and IR up to 30 meters; Uses H.265+ technology to reduce bandwidth usage by 50%; Intelligent motion detection that distinguishes between people and vehicles; Supports two-way communication via built-in microphone and speaker; IP67 rated waterproof and dust resistant, IK10 impact resistant; Supports MicroSD storage up to 512 GB
Is it in stock?
The VIGI InSight S245 4MP Full-Color Dome Camera 2.8mm Lens is in stock and ready to ship. Orders placed before 12:00 on a business day are delivered within 1–3 business days (Bangkok and vicinity) or 2–5 business days (other provinces). Order online at store.gist.co.th or contact our sales team at 092-251-4017.
How much does it cost?
The price is ฿2,088 (including 7% VAT). It is in stock and ready to ship. Business customers can request a quotation at sales@gist.co.th.
How long is the warranty?
The warranty follows the manufacturer's terms for each model; ask our sales team for the warranty period of this model. To make a warranty claim, call 092-251-4017 or 065-523-5262, or email sales@gist.co.th (Mon–Fri 9:00–18:00), then send the product with your order number to our head office, or bring it to the head office in person.
How long does delivery take?
Orders placed before 12:00 on a business day are delivered within 1–3 business days (Bangkok and vicinity) or 2–5 business days (other provinces). Free delivery on orders of ฿5,000 or more (a ฿150 delivery fee applies below this amount).
Is it genuine?
Genuine products sourced from distributors in Thailand, covered by the manufacturer's warranty. Full tax invoices are available.
