IMOU Ranger Mini 3MP 2K H.265 Indoor Camera with Integrated Bracket
SKU: IPC-K2MP-3H1WENetworking › IP Cameras (CCTV)
฿677
Price includes 7% VATPrice updated November 1, 2026
In stock2 years manufacturer's warranty
For orders placed before 12:00 on a business day; weekends excluded
GenuineFree delivery from ฿5,000Tax invoice
Indoor 3MP Ranger Mini CCTV camera with 2K resolution, supports color night mode, uses H.265 technology to save bandwidth, and features an integrated bracket for easy installation
Key features
- 2K resolution (2560 x 1440)
- Supports color night mode even at night
- Uses H.265 technology to save bandwidth
- Easy installation with built-in bracket
- Suitable for indoor use
Product description
The IMOU Ranger Mini 3MP CCTV camera model IPC-K2MP-3H1WE is designed for indoor use, delivering high-resolution 2K (2560 x 1440) video with a high-sensitivity image sensor for clear images even in low light. It supports Smart Color Night mode, enabling color recording at night. The H.265 technology reduces video file size and saves up to 50% bandwidth compared to H.264. The camera comes with an integrated bracket for immediate installation without additional mounting hardware. Ideal for use in homes, offices, or small retail stores.
More features
- Supports continuous video recording
- Has motion detection
- Supports Wi-Fi connectivity
- Compatible with IMOU app on both iOS and Android
- Built-in microphone for audio recording
Pros and limitations
Pros
- 2K resolution for sharp images even in low light
- Supports color night vision mode for improved detail visibility
- Uses H.265 technology to significantly reduce bandwidth usage
- Easy installation with built-in mount
- Supports up to 256 GB SD card storage
Limitations
- Does not support pan or angle adjustment
- Requires PoE or additional power cable for power supply
Who it is for
Ideal for home, office, or small retail store indoor surveillance with high-resolution recording even at night
Specifications (40)
- Lens
- 2.8 mm
- Size
- 108 x 108 x 75 mm
- Sensor
- 1/2.7" CMOS
- Weight
- 280 g
- Humidity
- 10% to 90% RH
- Mounting
- Wall or ceiling mount
- Protocol
- ONVIF, RTSP
- IP Rating
- IP65
- Frame rate
- 30 fps
- Night mode
- Smart Color Night
- Resolution
- 2K (2560 x 1440)
- Connectivity
- Wi-Fi 2.4 GHz
- Power supply
- PoE (802.3af)
- Infrared range
- 10 m
- Video encoding
- H.265
- Audio recording
- Built-in microphone
- Supports alerts
- Motion and sound detection
- Supports storage
- SD card (up to 256 GB)
- Power consumption
- 5 W
- Supports dual-stream
- Yes
- Operating temperature
- -10°C to 50°C
- Diagonal viewing angle
- 105°
- Supports TCP streaming
- Yes
- Supports UDP streaming
- Yes
- Supports Web streaming
- Yes
- Vertical viewing angle
- 55°
- App-based configuration
- IMOU App
- Supports HTTP streaming
- Yes
- Supports RTMP streaming
- Yes
- Horizontal viewing angle
- 90°
- Supports HTTPS streaming
- Yes
- Supports cloud streaming
- Yes
- Supports local streaming
- Yes
- Supports mobile streaming
- Yes
- Supports operating system
- iOS 11.0+, Android 6.0+
- Supports real-time streaming
- Yes
- Supports multi-view streaming
- Yes
- Supports multi-channel streaming
- Yes
- Supports multi-camera connectivity
- Yes
- Supports horizontal/vertical mounting
- Yes
Datasheets and manuals straight from the manufacturer — select a document to open or download it.
13 questions
Frequently asked questions about this product
Compiled from manufacturer information
Does the IPC-K2MP-3H1WE camera support ceiling or wall mounting?
Yes, this camera supports wall or ceiling mounting in both vertical and horizontal orientations, and comes with an adjustable built-in mount
Where does this camera draw power from?
This camera supports PoE (802.3af) power supply or external power cable, with approximately 5 watts of power consumption. A PoE-compatible power source or separate adapter is required
Can this camera record audio?
Yes, the camera has a built-in microphone and can record audio along with video, improving audio monitoring in the area
Does this camera support Wi-Fi connectivity?
Yes, the camera supports Wi-Fi 2.4 GHz connectivity and can be configured via the IMOU app on both iOS and Android
How many hours per day can this camera record video?
It depends on the recording settings, such as continuous or motion-activated recording. However, with H.265 technology, SD card lifespan is significantly extended. We recommend using an SD card with a capacity of 128–256 GB for optimal value
Can this camera work with ONVIF systems?
Yes, the camera supports ONVIF and RTSP protocols, enabling compatibility with various video management systems (VMS)
Can this camera be used with traditional CCTV systems?
Yes, the camera supports ONVIF and RTSP protocols, allowing it to work with existing CCTV systems that support these protocols
Does this camera have motion detection alerts?
Yes, the camera features motion and audio detection, and can send alerts through the IMOU app when activity is detected in the monitored area
Is it in stock?
The IMOU Ranger Mini 3MP 2K H.265 Indoor Camera with Integrated Bracket is in stock and ready to ship. Orders placed before 12:00 on a business day are delivered within 1–3 business days (Bangkok and vicinity) or 2–5 business days (other provinces). Order online at store.gist.co.th or contact our sales team at 092-251-4017.
How much does it cost?
The price is ฿677 (including 7% VAT). It is in stock and ready to ship. Business customers can request a quotation at sales@gist.co.th.
How long is the warranty?
Warranty period: 2-year warranty (manufacturer's terms). To make a warranty claim, call 092-251-4017 or 065-523-5262, or email sales@gist.co.th (Mon–Fri 9:00–18:00), then send the product with your order number to our head office, or bring it to the head office in person.
How long does delivery take?
Orders placed before 12:00 on a business day are delivered within 1–3 business days (Bangkok and vicinity) or 2–5 business days (other provinces). Free delivery on orders of ฿5,000 or more (a ฿150 delivery fee applies below this amount).
Is it genuine?
Genuine products sourced from distributors in Thailand, covered by the manufacturer's warranty. Full tax invoices are available.
